Product Parameter


Parameters
Channel CP-022:1 channel, CP-025:1 channel /3 channel
Frequency up to 10000Hz
Input Impedance ≥10MΩ
Response Frequency +3dB~-3dB @ 0.05~60Hz
Dynamic Input Range 10mV, polarization resistance voltage ±300mV
Pacemaker Detection can identify 2~200mV, 0.1~2ms pulse
Data Transmission USB data transfer, Bluetooth
Sampling Precision 16
Physical Specifications
Dimension 13 x 57 x 37 mm
Weight About 20g (lead wire not included)
Operating Enviroment
Temperature 5 ~ 45°C
Humidity 10 ~ 95% (No condensation)
Pressure 700~1060hPa
Battery
Type 3.7V Ni-HM battery inside
Supply Voltage Rated at 5V, 100mA
Battery life A maximum of 14 consecutive days of single-channel recording can be supported on a full charge
